CONSTRUCTION:

A 3-phase 415V AC supply is fed into a pulse rectifier circuit. This circuit utilizes controlled switching devices, such as thyristors or IGBTs, to achieve precise pulse-width modulation. The output is regulated from 0 to 415V AC and then connected to an step-down transformer. The secondary side of the transformer features diode rectifier, ensuring efficient conversion of the AC output to a stable DC voltage.

ADVANTAGES:

– Improved Efficiency

Reduced Harmonics

Controlled Output

Compact Design

Thermal Management

– Faster Response Time

Lower Electromagnetic Interference (EMI)

FEATURES:

-High reliability

-Precise control

-Robust thermal management

-Low harmonic distortion

-Low noise operation

RANGE:

DC Voltage: 0 to 100VDC

DC Amps: 0 to 5000Amps
